PLEASE ASK FOR PRICE!
Working temperature: 0°C ÷ +100°C
Non linearity + hysteresis: < 5% of the end of scale at 20°C
Zero thermic drift: < 3% of the end of scale from
Weight: 0,07 Kg
Body: in nickel plated brass with wetted parts in nickel plated brass and integral seal in NBR
Electric Features:
- Power supply standard executions:
4-20 mA à 2 wires: from 12 to 24 VDC
0-10 V à 3 wires: from 12 to 24 VDC
- Electric connection according to DIN43650, M3
- Electric connection according to IEC60947-5-2, M12
- Electric protection according to CEI EN 60529, IP65 (M3, M12)
Warranty: see dedicated page
Spare parts: see dedicated page
Also available:
- TT4X with body in AISI 316L stainless steel (minimum required lot)
- TT4..P with an extension to intercept fluid into a tank
- Special electrical connection
- Different measurement pressure ranges
- CU-TR for Russian market
