SD5 Monoblock Directional Control Valve | 40–60 L/min Hydraulic Valve

Brand: Walvoil
Product Code: SD5
Availability: In Stock

0.00€
Ex Tax: 0.00€

Available Options

Other Product Code:

SD5/2--P
P0500001
102219002
SD5/1-P
SD5/2-P
SD5/3-P
SD5/4-P
SD5/5-P
SD5/6-P
SD5/7-P
SD5/2-P(JG3-120)/18L/18L/AET-SAE
SD5/2-P(JG3-120)/18L/18L/AET-SAE-PSA
SD5 / 2 - P (JG3-120) / 1 8 L / 1 8IM . P3(G3-100) / AET - SAE
1-P 5KC1197000 Parallel, 1 section
2-P 5KC1227000 Parallel, 2 sections
3-P 5KC1247000 Parallel, 3 sections
4-P 5KC1277000 Parallel, 4 sections
5-P 5KC1317000 Parallel, 5 sections
6-P 5KC1357000 Parallel, 6 sections
7-P 5KC13E7000 Parallel, 7 sections
(JG2--63) 5KIT105412 Range 40 to 63 bar / 580 to 900 psi standard setting 63 bar / 900 psi
(JG3--120) 5KIT105413 Range 50 to 200 bar / 725 to 2900 psi standard setting 120 bar / 1750 psi
(JG4--220) 5KIT105414 Range 160 to 315 bar / 2300 to 4600 psi standard setting 220 bar / 3200 psi
SV XTAP623282 Relief valve blanking plug
1 3CU1210130 Double acting, 3 positions, with A and B closed in neutral position
1A 3CU1221130 Double acting, 3 positions, with A open to tank in neutral position
1B 3CU1222130 Double acting, 3 positions, with B open to tank in neutral position
2 3CU1225130 Double acting, 3 positions, with A and B open to tank in neutral position
2H 3CU1225225 Double acting, 3 positions, with A e B partially open to tank in neutral position
3 3CU1231130 Single acting on A, 3 positions, B plugged requires G3/8 plug (see part I )
5DY 3CU1242220 Double acting, 4 positions, floating circuit in 4th position with spool in
5PY 3CU1245620 Double acting, 4 positions, floating circuit in 4th position with spool out, with check valve
8 3CU1262120 Double acting, 4 positions, regenerative circuit in 4th position with spool in
8F 3CU1261100 Double acting, 3 positions, regenerative circuit in 2nd position with spool out
8 5V08105000 With spring return in neutral position
8D 5V08105200 With spring return in neutral position and pin with M6 female thread for dual control
8D2 5V08105220 With spring return in neutral position and pin with M8 male thread for dual control
8F2 5V08105101 With spring return in neutral position and adjustable flow limiter
19 5V19105000 2 positions, with spring return in neutral position from position 1
20 5V19105000 2 positions, with spring return in neutral position from position 2
9 5V09105010 With detent in position 1 and spring return in neutral position
10 5V10105010 With detent in position 2 and spring return in neutral position
11 5V11105000 Detent in positions neutral, 1 and 2
12 5V12105000 Detent in positions 1 and 2
15 5V15105000 2 positions, detent in positions 1 and neutral
16 5V16105000 2 positions, detent in positions 2 and neutral
9BZ 5V09202010 With detent in position 1 and spring return in neutral position
10BZ 5V10202010 With detent in position 2 and spring return in neutral position
11BZ 5V11202010 Detent in positions 1 and 2 and spring return in neutral position
8K 5V08705112 With spring return in neutral position and 12 VDC spool solenoid lock device
5V08705124 As previous, 24VDC
8RM2 5V08105590 With spring return in neutral position and
12VDC electromagnetic detent in pos. 2
5V08105595 As previous, 24VDC
8MHE3(NC) 5V08105541 With spring return in neutral position and spool postioning ON/OFF electric signal circuit normally closed
8MHE3(NO) 5V08105540 As previous, with circuit normally open
8MS3 5V08105553 With spring return in neutral position, operation signalling in position 1 and 2, prearranged for centralized microswitch control: need KM connection kit
8MG3(NO) 5V08105660 With spring return in neutral position and microswitch in positions 1 and 2
8P 5V08105701 ON/OFF pneumatic kit
8EP3 5V08105735 ON/OFF 12 VDC electro--pneumatic kit
5V08105740 ON/OFF 24 VDC electro--pneumatic kit
8ED3 5V08105350 ON/OFF 12 VDC electro--hydraulic kit
5V08105351 ON/OFF 24 VDC electro--hydraulic kit
SAE6 3XTAP817130 For single acting spool type 3
13NZ 5V13305010 4 pos. with spring return in neutral pos. and detent in 4th pos.: for spool 5DY
13QN 5V13405020 4 pos. with spring return in neutral pos. and detent in 4th pos.: for spool 5PY
13FZ 5V13505400 4 positions with spring return in neutral position: for spool 8
13QNMG3(NO) 5V13405660 As type 13QN with microswitch in positions 1 and 2: for spool 5PY
L 5LEV105000 Standard lever box
LM10 5LEV205000 Lever box for M10 handlever
LF1 5LEV105102 Lever box with adjustable flow limiter
LEB 5LEV605000 Safety lever box, vertical configuration
LUP 5LEV805005 Safety lever box, horizontal configuration
SLP 5COP105000 Witout lever box, with dust--proof plate
SLC 5COP205000 Witout lever box, with endcap
TQ 5TEL105110 Flexible cable connection
LCB 5CLO205100 Joystick lever for 2 sections operation
AET XTAP623170 Open centre plug
AEK 3XTAP522282 Closed centre plug
AE 3XGIU527470* SAE8 power beyond sleeve
AET--L 5CAR405700* With hydraulic pilot unloader valve
AET--LT XTAP523370 Unloader valve blanking plug
Electric control unloader valve: for valves and coils list see page 50.
PSL 3XTAP822150 Side ports; need n.2 SAE8 plugs, standard configuration (omit in valvedescription)
PSA 3XTAP822150 Upper ports; need n.2 SAE8 plugs
AL01/M8x120 170011012 For lever L: height 120 mm / 4.72 in
AL01/M10x150 170012015 For lever LM10: height 150 mm / 5.91 in
AL08/M12x150 170013115 For joystick LCB: height 150 mm / 5.91 in
VMD5 (JG3-120)
12 VDC 5V08705112 5V08705412 5V08705612
24 VDC 5V08705124 5V08705424 5V08705624
12 VDC 2X4300012 2X4300014 YSOL300013
24 VDC 2X4300024 2X4300026 YSOL300025
12 VDC 5V08105590 5V08105591 5V08105593
24 VDC 5V08105595 5V08105596 5V08105598
12 VDC YSOL532455 YSOL532452 YSOL532451
24 VDC YSOL532456 YSOL532458 YSOL532457
SD5/2-P(JG3-120)/18MS3L/18MS3L/AET - KM 2 S 51 - SAE
KM1S51 5KM1S5102 Kit for 1 section
KM2S51 5KM2S5102 Kit for 2 sections
KM3S51 5KM3S5102 Kit for 3 sections
KM4S51 5KM4S5102 Kit for 4 sections
KM5S51 5KM5S5102 Kit for 5 sections
KM6S51 5KM6S5102 Kit for 6 sections
KM7S51 5KM7S5102 Kit for 7 sections
5MIC200
5V08105660 5V08105680 5V08105670 C07 see page
NC 5V08105662 5V08105682 5V08105672 C17
5KIT820500
5KIT820501
5KIT820502
12 VDC 5V08105735 5V08105736
24 VDC 5V08105740 5V08105741
12 VDC 2X4000013 2XB1000120000
24 VDC 2X4000025 2XB1000240000
12 VDC 5V08105350 5V08105250 5V08105280 5V08105450
24 VDC 5V08105351 5V08105251 5V08105281 5V08105451
12 VDC 2XB1400121100 2XB1400121200 2XB1400121210 2XB1400120400
24 VDC 2XB1400241100 2XB1400241200 2XB1400241210 2XB1400240400
KE1S0 5KE1S00070 Kit one section
KE2S0 5KE2S00270 Kit for 2 sections
KE3S0 5KE3S00270 Kit for 3 sections
KE4S0 5KE4S00270 Kit for 4 sections
KE5S0 5KE5S00270 Kit for 5 sections
KE6S0 5KE6S00270 Kit for 6 sections
SD5/2-P(JG3-120)/18ED3L/18ED3L/AET-SAE-KE2S0-24VDC
KE1R0 5KE1R30270 Kit one section
KE2R0 5KE2R30270 Kit for 2 sections
KE3R0 5KE3R30270 Kit for 3 sections
KE4R0 5KE4R30270 Kit for 4 sections
KE5R0 5KE5R30270 Kit for 5 sections
KE6R0 5KE6R30270 Kit for 6 sections
X003600010
5V13405660 NO C07
5V13405661 NC C17
12 VDC 2X4300012 2X4300014 YSOL300013
24 VDC 2X4300024 2X4300026 YSOL300025
SD5 / 1 - P (JG3-120) / 1 8ESN LES / AET - SAE - 24VDC
SD5/1-P 5KC1197100 1 section, standard body
SD5/2-PS 5KC1227003 2 sections, special body
SD5/3-PS 5KC1247004 3 sections, special body
1(ESN) 3CU1210036 Double acting, 3 positions, with A and B closed in neutral position
2(ESN) 3CU1225036 Double acting, 3 positions, with A and B open to tank in neutral position
8ESN 5V08009 For solenoid joint, with spring return in neutral position
LES 5LEV105410 Safety lever pivot box for manual operation
CAE 5COP205100 Endcap
10.5VDC XSOL314310 Nominal voltage 10.5VDC
12VDC XSOL314312 Nominal voltage 12VDC
24VDC XSOL314324 Nominal voltage 24VDC
192VDC XSOL314192 Nominal voltage 192VDC; (for 220 VAC supply)
SD5 / 1 - P (JG3-120) / 1 8ES3 4 / AET - SAE - 24VDC
SD5/1-P 5KC1197100 1 section
SD5/2-P 5KC1227100 2 sections
SD5/3-P 5KC1247100 3 sections
SD5/4-P 5KC1277100 4 sections
SD5/5-P 5KC1317100 5 sections
SD5/6-P 5KC1357100 6 sections
SD5/7-P 5KC13E7100 7 sections
1(ES) 3CU1210011 Double acting, 3 positions, with A and B closed in neutral position
2(ES) 3CU1225010 Double acting, 3 positions, with A and B open to tank in neutral position
SAE6 3XTAP817130 For single acting controls type 8ES1 and 8ES2
8ES1 5CAN08024 Single acting PA, with spring return to neutral position
8ES2 5CAN08024 Single acting PB, with spring return to neutral position
8ES3 5CAN08025 Double acting,with spring return to neutral position
10.5VDC 4SOL412012 Nominal voltage 10.5VDC
12VDC 4SOL412012 Nominal voltage 12VDC
24VDC 4SOL412024 Nominal voltage 24VDC
4-10.5VDC 4SOL412111 Nominal voltage 10.5VDC
4-12VDC 4SOL412112 Nominal voltage 12VDC
4-24VDC 4SOL412124 Nominal voltage 24VDC
5IDR205071
SD5 / 2 - P (JG3-120) / 18L / 18L / AET-ELNW 4 (NC) - SAE - 12VDC
SD5/2-P(JG3-120)/18L/18L/AET-ELNW-SAE-12VDC
SD5/2-P(JG3-120)/18L/18L/AET-ELNW(NC)-SAE-12VDC
AET--ELNW 0EFW0132002 Normally open, without emergency
AET--ELNW(NC) 0EFW0132003 As previous, normally closed
AET--ELTW 0EFW0132000 Normally open, with “push&twist” emergency type
AET--ELPW 0EFW0132001 Normally open, with push--button emergency type
12VDC 4SLE001200 Nominal voltage 12VDC
DB-12VDC 4SLE001217 As previous, with bi--directional diode
24VDC 4SLE002400 Nominal voltage 24VDC
DB-24VDC 4SLE002408 As previous, with bi--directional diode
2-12VDC 4SLE001203 Nominal voltage 12VDC
2DB-12VDC 4SLE001211 As previous, with bi--directional diode
2-24VDC 4SLE002403 Nominal voltage 24VDC
4-12VDC 4SLE001202 Nominal voltage 12VDC, parallel connection
4DB--12VDC 4SLE001216 As previous, with bi--directional diode
4PD-12VDC 4SLE001201 Nominal voltage 12VDC, perpendicular connection
4PDDB--12VDC 4SLE001209 As previous, with bi--directional diode
4-24VDC 4SLE002402 Nominal voltage 24VDC, parallelconnection
4PD-24VDC 4SLE002401 Nominal voltage 24VDC, perpendicular connection
4PDDB-24VDC 4SLE002407 As previous, with bi--directional diode
SD5/2-P(JG3-120)/18L/18L/AET-LT-SAE
VS(G3-100) 3XCAR505113 Range 40 to 200 bar / 580 to 2900 psi standard setting 100 bar / 1450 psi
VST 3XTAP419300 Valve blanking plug
VSC(JG2-60) 5KIT105412 Range 40 to 80 bar / 580 to 1150 psi standard setting 60 bar / 870 psi
VSC(JG3-100) 5KIT105413 Range 63 to 200 bar / 900 to 2900 psi standard setting 100 bar / 1450 psi
VSC(JG4-200) 5KIT105414 Range 160 to 250 bar / 2300 to 3600 psi standard setting 200 bar / 2900 psi
VSCT XTAP623282 Valve blanking plug
Kit VS 5CO2420000 Mounting block kit
VSC(JG2-60) 5KIT105412 Range 40 to 80 bar / 580 to 1150 psi standard setting 60 bar / 870 psi
VSC(JG3-100) 5KIT105413 Range 63 to 200 bar / 900 to 2900 psi standard setting 100 bar / 1450 psi
VSC(JG4-200) 5KIT105414 Range 160 to 250 bar / 2300 to 3600 psi standard setting 200 bar / 2900 psi
VSCT XTAP623282 Valve blanking plug
Kit VS 5CO2420000 Mounting block kit
BPS1 602003005* Block with valve on port A
BPS2 602003005* Block with valve on port B
BPS3 602003105* Block with valves on ports A and B
BPS XCAR605210 Single valve
BPT XTAP627300 BP and BPS valves blanking plug
P1(D3-100) 602001007* Block with valve on port A
P2(D3-100) 602001007* Block with valve on port B
P3(D3-100) 602001101* Block with valves on ports A and B
P(D2-60) 5CAR211112 Single valve: range 40 to 100 bar / 580 to 1450 psi,standard setting 60 bar / 870 psi
P(D3-100) 5CAR211113 Single valve: range 80 to 200 bar / 1150 to 2900 psi, standard setting 100 bar /1450 psi
P(D4-200) 5CAR211113 Single valve: range 180 to 315 bar / 2600 to 4600 psi, standard setting 200 bar / 2900 psi
PT XTAP526430 Valve blanking plug (for configurationP1,P2)
VM(50) 5KIT326050 Setting 50 bar / 725 psi
VM(60) 5KIT326060 Setting 60 bar / 870 psi
VM(70) 5KIT326070 Setting 70 bar / 1010 psi
VM(80) 5KIT326080 Setting 80 bar / 1150 psi
VM(90) 5KIT326090 Setting 90 bar / 1300 psi
VM(100) 5KIT326100 Setting 100 bar / 1450 psi
VM(125) 5KIT326125 Setting 125 bar / 1800 psi
VM(140) 5KIT326140 Setting 140 bar / 2050 psi
VM(160) 5KIT326160 Setting 160 bar / 2300 psi
VM(175) 5KIT326175 Setting 175 bar / 2550 psi
VM(190) 5KIT326190 Setting 190 bar / 2750 psi
VM(210) 5KIT326210 Setting 210 bar / 3050 psi
VM(230) 5KIT326230 Setting 230 bar / 3350 psi
VM(250) 5KIT326250 Setting 250 bar / 3600 psi
VM(260) 5KIT326260 Setting 260 bar / 3750 psi
VM(280) 5KIT326280 Setting 280 bar / 4050 psi
VM(300) 5KIT326300 Setting 300 bar / 4350 psi
VMT XTAP221340 Valve blanking plug
Kit VM 5CO2820020 Mounting block kit
Kit V 5CO2820010 Mounting block kit
T XTAP524280 Valve blanking plug
C 5KIT406110 Anti-cavitation valve
P(G2) 5KIT206112 Range 60 to 125 bar / 870 to 1800 psi standard setting 80 bar / 1150 psi
P(G3) 5KIT206113 Range 80 to 200 bar / 1150 to 2900 psi standard setting 120 bar / 1750 psi
P(G4) 5KIT206114 Range 160 to 250 bar / 2300 to 3600 psi standard setting 200 bar / 2900 psi
U(G2) 5KIT305112 Range 40 to 100 bar / 580 to 1450 psi standard setting 80 bar / 1150 psi
U(G3) 5KIT305113 Range 80 to 200 bar / 1150 to 2900 psi standard setting 120 bar / 1750 psi
U(G4) 5KIT305114 Range 160 to 315 bar / 2300 to 4600 psi standard setting 200 bar / 2900 psi
VD11 2S0PP10002000 Fine regulation from 3 to 30 l/min
VD12 2S1636020211 As VD11, one turn with detent
VD13 2S0PP10002002 12VDC proportional solenoid valve
Kit VD1 5CO2822015* Mounting block kit
VS (G3-100)
SD5/2-P(KG3-120)/18L/VS(G3-100)/18L/AET-SAE-PSA
VSC (JG3-100)
SD5/2-P(JG3-120)/18L/VSC(JG3-100)/18L/AET-SAE
P1 (D3-100)
5LEV105050
VM1 (100)
VP1 (G3-100)
VU1 (G3-100)
SD5/2-P(JG3-120)VD11/18L/18L/AET-SAE
SD5/2-P(JG3-120)VD12/18L/18L/AET-SAE
SD5/2-P(JG3-120)VD13/18L/18L/AET-SAE
SD5/1-N(JG3-120)/18L-SAE 102110118
SD5/1-D(JG3-120)/18L-SAE 102160032
SD5/2-S
SD5/3-S
SD5/4-S
SD5/5-S
SD5/6-S
5KC1157040 SD5/2-S1
5KC1257000 SD5/3-S1
5KC12D7000 SD5/3-S1+1
5KC1287000 SD5/4-S1
5KC12E7000 SD5/4-S1+1+1
5KC1327003 SD5/5-S1
5KC1077001 SD5/5-S1+1+1+1
5KC13A7000 SD5/5-S2+1
5KC1367000 SD5/6-S1
SD5/4-S1(JG3-120)/18L/18L/18L/18L-SAE 1024B0028
SD5/2-SP1
SD5/3-SP2
SD5/4-SP3
SD5/5-SP4
SD5/6-SP5
SD5/7-SP6
5KC1187000 SD5/2-SP1
5KC12G7000 SD5/3-SP2
5KC1307000 SD5/4-SP1
5KC12H7000 SD5/4-SP1+2
5KC12I7000 SD5/4-SP2+1
5KC1297000 SD5/4-SP3
5KC13D7000 SD5/5-SP2+2
5KC1347000 SD5/5-SP3+1
5KC1337000 SD5/5-SP4
5KC1397000 SD5/6-SP3+1
5KC13Y7000 SD5/6-SP3+2
5KC1377000 SD5/6-SP5
5KC13J7000 SD5/7-SP3+1
5KC13G7000 SD5/7-SP4
5KC13L7000 SD5/7-SP5+1
5KC13F7000 SD5/7-SP6
SD5/4-SP3(JG3-120)/18L/18L/18L/18L/AET-SAE 1024A0019
SD5/2-P
P0500001
102219002

Qty

0 reviews / Write a review

Description
Reviews (0)

PLEASE ASK FOR PRICE!

The Walvoil SD5 is a high-performance monoblock directional control valve designed for mobile and industrial hydraulic systems requiring precise flow control, durability, and flexible configuration. With a nominal flow range up to 60 L/min and a maximum operating pressure of 315 bar, the SD5 series is widely used in medium-duty hydraulic applications where reliability and efficiency are critical.

Its modular design allows multiple spool configurations, making it suitable for complex hydraulic circuits in agricultural, construction, and material handling machinery. The SD5 is engineered for long service life, smooth operation, and easy integration into OEM hydraulic systems.

Features

Nominal flow rate: up to 60 L/min
Maximum operating pressure: 315 bar
Modular monoblock construction
Multiple spool configuration options
Compatible with open-center and closed-center systems
Manual, hydraulic, pneumatic, and electro-hydraulic control options
Auxiliary port valve compatibility
Compact and robust design for mobile applications
High precision flow control and smooth actuation

Applications

Agricultural machinery
Construction equipment
Forestry machines
Material handling systems
Truck-mounted equipment
Industrial hydraulic systems
Loaders and excavators
Mobile hydraulic power units

Technical Specifications

Specification	Value
Model	Walvoil SD5
Valve Type	Monoblock Directional Control Valve
Nominal Flow	up to 60 L/min
Maximum Pressure	315 bar
Sections	Multiple (configurable)
Control Options	Manual, Hydraulic, Pneumatic, Electro-hydraulic
Hydraulic System	Open Center / Closed Center

Why Choose Walvoil SD5?

The Walvoil SD5 combines durability, flexibility, and high hydraulic performance in a compact monoblock design. It is ideal for OEM manufacturers and service providers who require a reliable and adaptable valve platform. Its wide range of configurations makes it one of the most versatile solutions in mobile hydraulics.

SD5_Monoblock_Directional_Control_Valves.pdf

Tags: Walvoil, Walvoil SD5, SD5, Monoblock Valve, Hydraulic Valve, Directional Control Valve, Hydraulic Directional Valve, Hydraulic Control Valve, Hydraulic Spool Valve, Modular Hydraulic Valve, Mobile Hydraulics, 60 L/min Valve, 315 Bar Valve, Agricultural Machinery Valve, Construction Equipment Valve, Forestry Equipment Valve, Material Handling Valve, Truck Hydraulic Valve, OEM Hydraulic Valve, Hydraulic Components, Walvoil Hydraulic Parts,
