93T Proline Prosonic Flow ultrasonic flowmeter

The economical flowmeter for easy data transfer via USB stick without additional software

Previous: Prosonic Flow Clamp On 92TA1

• Measuring principle

  Ultrasonic flow

• Product headline

  Portable volume flowmeter for measurement of liquid applications; from outside of the pipe with "Clamp On" sensors

• Sensor features

  Integrated USB data logging

• Nominal diameter range

  DN 15...65
  - 1/2"...2 1/2" (-40...+100°C or -40...+150 °C)
  DN 50...300
  - 2"...12" -40...+80 °C or 0...+170 °C)
  DN 100...4000
  - 4"...160" (-40...+80 °C)

• Max. measurement error

  +/-2.0 %

• Measuring range

  0....452'389 m3/h

• Max. process pressure

  No limit

• Medium temperature range

  DN 15...65
  -40...+150°C
  (-40...+302°F)
  DN 50...300
  -40...+170°C
  (-40...+338°F)
  DN 100...4000
  -40...+80°C
  (-40...+176°F)

• Degree of protection

  IP 40

• Display/Operation

  Four line backlit
  touch control

• Outputs

  Integrated data logger/site manager
  Easy data transfer via USB stick without additional software

• Inputs

  4...20mA

• Digital communication

  FXA 193

The portable ultrasonic flowmeter Prosonic Flow 93T is designed for temporary monitoring and test measurements with clamp on sensors. It is operated independently of the mains power using a battery. The Prosonic Flow 93T is ideal for conducting verification measurements at existing flow metering points.

The sensors are perfectly suited for the non-contact measurement of pure or slightly contaminated liquids, regardless of the pressure or electrical conductivity.

• Ideal solution for temporary use everywhere precise measurement or verification is required

• Can be used with all metal and plastic pipes lined or unlined and with composite pipes

• Suitable for pipe diameters from DN 15 to 4000 (½ to 160")

• Suitable for fluid temperatures ranging from –40 to +170 °C (–40 to +338 °F)
