Working temperature of the instrument: -10°C ÷ +70°C
Working temperature of the fluid: 0°C ÷ +100°C
Switching precision: < ±2% of the end of scale to 20°C
Hysteresis value: freely adjustable over full scale
Zero thermal drift : < 3% of the end scale from 0°C to +70 °C
Weight: 0,24 Kg
Mechanical life: 2x106 cycles a 20°C
Body: in anodized aluminium, with wetted parts in brass
Electric Features:
- Maximum contact load: 0,5 A
- Medium consumption: <50 mA
- Power supply: from 10 to 30 Volt
- Electric connection according to DIN43650, M3
- Electric connection according to IEC60947-5-2, M12
- Electric protection according to CEI EN 60529, IP65
- Output signal 4-20mA combinable to contacts (only with M12 connector)
- Interference emission and immunity according to EN 61.326
Warranty: see dedicated page
Spare parts: see dedicated page
On request:
- Special electrical connection
- Special value of hysteresis
- CU-TR for Russian market
- Special hydraulic connection
