CED040 Dedicated configuration

PLEASE ASK FOR PRICE!

Dedicated configuration for Front Loader application, for SDM122/DLM122 series with mecahtronic control.


Voltage supply: from 9 to 16 V
Current: < 50 mA
Total maximum output current: 15 A
Maximum output current per pin: 7.5 A
Connector: Deutsch DTM13-12PA - Deutsch DTM13-12PB
Weather protection: IP67
Working temperature: from -40 to 85 °C (from -40 to 185 °F)
Storage temperature: from -40 to 85 °C (from -40 to 185 °F)
Maximum working temperature [°C]: 85
Maximum storage temperature[°C]: 85
Number of CANbus ports: 1
Number of analog inputs: 3
Number of temperature inputs: 0
Number of digital inputs: 6
Number of low side outputs: 0
Number of high side outputs: 4 (relay)
Number of 5V outputs: 0
